Heat Shirnkable LV Straingth Through Joints suitable for PVC/XLPE/PILC Cables upto 3.3KV
GLH /GCH -1100
Descriptions:
GLH/GCH - 1100 - Series kits are heat shrinkable type Straight Through Joints, designed for 1,2,3,3½,4 core extruded solid dielectric (XLPE/PVC) & Paper Insulated lead cables armoured/unarmoured of 1.1KV & 3.3KV voltage rating. Our kits has been designed to provide the basic important functions required for LV(Un-screened) power cable including the electrical performance, environmental seal, mechanical fatigues & other related performance parameters laid down in different Countries for various service conditions. These are designed, manufactured and tested according to requirements of the local & internationally accepted standards
Salient Features:
- Fits a wide dimensional range.
- Excellent electrical, thermal & mechanical performance.
- Accommodation of tolerances, different conductor cross sections & cable constructions.
- No shelf life limitations upto or below 50 deg C.
- Pre-designed components for easy & reliable installation.
- Each kit contains easy to follow instructions with well explained visual & graphics for step wise installation methods.
- Exceptional Insulation properties.
- High tracking resistance in harsh environment.
Specifications:
| Test Sequence | Requirement Test Value | Results |
|---|---|---|
| A.C. Voltage Withstand, 5 Min | 3.5 kV | 5 kV |
| D.C. Voltage Withstand, 15 Min | 15 kV | 5 kV |
Order Reference:
| Cable Range (Sq. mm) | Kit Code 1.1 KV | Kit Code 3.3 KV |
|---|---|---|
| 4 x 1.5-6 | GLH-01 | GCH-11 |
| 4 x 10-16 | GLH-02 | GCH-12 |
| 4 x 25-50 | GLH-03 | GCH-13 |
| 4 x 70-120 | GLH-04 | GCH-14 |
| 4 x 150-240 | GLH-05 | GCH-15 |
| 4 x 300-400 | GLH-06 | GCH-16 |
